ROS 2 across Docker containers: shared network, discovery and Fast DDS shared memory

How ROS 2 nodes find each other

#

ROS 2 has no master. Nodes discover each other through DDS — in Jazzy, eProsima Fast DDS by default — using the SPDP protocol:

1. Each participant announces itself over UDP multicast (239.255.0.1) on ports derived from the domain ID \(d\): discovery multicast on \(7400 + 250d\), unicast on \(7410 + 250d + 2p\) for participant \(p\). For domain 42: UDP 17900 and 17910+.
2. Peers exchange their topic endpoints; matching publishers and subscribers connect.
3. Data flows over the best transport both support — shared memory when they share a host and /dev/shm, UDP otherwise.

Why Docker’s default network breaks it

#

Compose attaches services to a bridge network — a private NATed subnet. Multicast isn’t reliably routed across it, and machines on your LAN can’t reach container IPs at all.

network_mode: host removes the network namespace: the containers use the host’s interfaces directly, and discovery behaves as if ROS were installed natively.

Scope: domain ID and discovery range

#

ROS_DOMAIN_ID: 42
ROS_AUTOMATIC_DISCOVERY_RANGE: SUBNET

• ROS_DOMAIN_ID=42 partitions the DDS space. Work on the default domain 0 stays separate; pick any free 0–101.
• ROS_AUTOMATIC_DISCOVERY_RANGE (Jazzy and later):

From another computer:

export ROS_DOMAIN_ID=42
ros2 topic echo /hand/target_flexions

Nothing arrives? Same subnet, host firewall open for UDP 17900–17930, and no Wi-Fi client isolation or multicast filtering. For networks that drop multicast, set static peers with ROS_STATIC_PEERS=<ip> (Jazzy+) or use a wired link.

Shared memory: the fast path between the containers

#

Fast DDS’s shared-memory transport writes a message once into a segment under /dev/shm, and the subscriber reads it in place — no UDP packets, no kernel network stack, no loopback copies. Across containers, that needs sharing:

Evidence

#

During testing, a subscriber in mujoco_twin received a JointState published from vision_tracker. While it ran, the vision container listed Fast DDS segments — including those of the subscriber living in the other container:

$ ls /dev/shm | grep fast        # inside vision_tracker
fastrtps_5a080c43d95a7658
fastrtps_5a080c43d95a7658_el
fastrtps_837f37c7f519d02a
fastrtps_837f37c7f519d02a_el
fastrtps_port17913

fastrtps_port17913 follows the same RTPS port formula as UDP for domain 42: \(7400 + 250 \times 42 + 11 + 2 \times 1 = 17913\), the unicast user-data port of participant 1. The *_el files are segment locks. All of it is visible to both containers only because of ipc: host.

flowchart LR
    subgraph VT["🐳 vision_tracker"]
        P["publisher"]
    end
    subgraph MT["🐳 mujoco_twin"]
        S["subscriber"]
    end
    P -- "write once" --> SHM[("/dev/shm
fastrtps_* segments
ipc: host")]
    SHM -- "read in place" --> S
    P -. "discovery · UDP 17900+
network_mode: host" .- S

Does it matter for five floats?

#

Not much — UDP loopback would carry five floats at 30 Hz fine. Shared memory earns its keep once you publish images: streaming the annotated camera frame as sensor_msgs/Image is about 0.9 MB per 640×480 RGB frame, 30 times a second. The configuration is in place so that extension is free.

What it costs, and how to harden it

#
